Odd Parity Generator

  1. Fill the truth table and click on 'CHECK' button.
  2. Click on the components button to place the component.
  3. Make connections as per the circuit diagram.
    4. Fig. 1 Circuit diagram of odd parity generator.


    Fig: 2 Pin diagram of IC-7486 and IC-7404.

  4. Feed input A and B to one gate of IC and input C to another gate.
  5. Click on 'Check Connections' button. If connections are right, the 'Start Simulation' button will become active. Click on it to start simulation.
  6. Click on the toggle buttons 'A', 'B' and 'C' to perform simulation.

TRUTH TABLE

Components button will remain inactive until Truth-Table is filled correctly.

   INPUTS
A        B        C 		PARITY BIT
P
0           0          0
0           0          1
0          1          0
0          1          1
1          0          0
1          0          1
1          1          0
1          1          1
